RAL6005 녹색 V 메쉬 펜싱 PVC 코팅 3M 야외 보안 울타리
  • RAL6005 녹색 V 메쉬 펜싱 PVC 코팅 3M 야외 보안 울타리
  • RAL6005 녹색 V 메쉬 펜싱 PVC 코팅 3M 야외 보안 울타리

RAL6005 녹색 V 메쉬 펜싱 PVC 코팅 3M 야외 보안 울타리

원래 장소 허베이, 중국
브랜드 이름 Giant Fence
인증 ISO14001:2015/OHSAS 18001:2007/ ISO9001:2015
모델 번호 GF004
제품 세부 사항
모델 번호:
3D V 메쉬 보안 펜싱
와이어 직경:
6.0mm
개구 사이즈:
50*200mm
높이:
1730/1830 밀리미터
아니오 구부러지기:
3
표면 처리:
입히는 Galvanized+PVC
색:
녹색 RAL6005
재료:
저탄소강선
포스트 유형:
사각형 포스트
용법:
정원 울짱, 스포츠 울타리, 농가 울타리
강조하다:

3M 높이 야외 보안용 펜스

,

PVC는 야외 보안 Fence

,

RAL6005 녹색 V 메쉬 펜싱을 코팅했습니다

지불 및 배송 조건
최소 주문 수량
50sets
가격
negotiable
포장 세부 사항
팔레트와 포스트와 컨테이너 2.panel의 모든 크기가 3.panel을 부피를 크게 합니다 그리고 팔레트와 모든 포장을 부치세요 1.panel과 포스트
배달 시간
18-21days
지불 조건
전신환, L/C (신용장), 인수 인도, D/P (지급도 조건), 웨스턴 유니온, 머니그램
공급 능력
1주일에 5000 미터
제품 설명

Rectangle Post Outdoor Security PVC Coated V Mesh Security Fencing



V Mesh Security Fencing with Rectangle Post Description

  1. V Mesh Security Fencing with Rectangle Post are made of high quality steel ,covered with excellent anti corrosion coating to ensure the fence has long time use.
  2. The panels feature 'V' shaped beams at the top, centre and bottom edges, which not only enhance the appearance but also provide an integral support spanning between the posts.
  3. Welded wire mesh fence is consist of wire mesh fence panel ,fence post and clamp and bolts.

V Mesh Security Fencing Specification



Material Low carbon steel, hot galvnaized steel
Height 800mm, 1000mm, 1200mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm
Post distance 2000mm, 2500mm
Wire diameter 4.0mm, 4.5mm, 5.0mm, 6.0mm
Mesh size 50 x 200mm
Post Square post: 50 x 50mm, 60 x 60mm, 80 x 80mm
Rectangle post: 40 x 60mm, 40 x 80mm, 50 x 70mm
Peach post: 50 x 70mm, 70 x 100mm
I post: 44 x 70mm, 55 x 100mm
Surface treatment Low carbon steel+hot dipped galvanized
Hot galvanized steel+powder coated
Hot galvanized steel+pvc coated
Color dark green, black, white, yellow, grey, blue and so on



Peach post Specification



Post view Size Thickness Panel height Base post Normal post Surface treatment
Square post

40*40mm

50*50mm

60*60mm

1.0mm

1.1mm

1.2mm

1.5mm

1.8mm

2mm

2.5mm

830mm 850mm 1200mm

1.Black tube Hot-dipped galvanized

2.Galvanized tube PVC coated

1030mm 1050mm 1400mm
1230mm 1250mm 1600mm
1530mm 1550mm 2000mm
Rectangle post

30*50mm

40*60mm

60*80mm

1830mm / 2400mm
2030mm / 2500mm
2230mm / 2800mm
2430mm / 3000mm



V Mesh Security Fencing Application

  1. Commercial grounds (Corporation, hotel, supermarket)
  2. Private grounds (Courtyard, Villadom)
  3. Public grounds (Park, zoo, train or bus station, lawn);
  4. Road and transit (Highway, railway or road city transit);
  5. 3D fence is used as decoration or protection for various facilities in industry,agriculture, transport, etc.

3D Fence process



1.Purchase the raw material wire--Zn/Ai coating test--Straightening and cutting--welding panel--Bending--Powder coating or PE coating--loading

2.Post cutting--punching hole on the post -- Powder coating--Loading



Service



1: Product Service

Our products offer 10 YEARS GUARANTEE.



2: Product customization services

We can customize products according to your requirements, including design and drawing.



3: After-sales service

Our after-sales service start immediately after signing the contract.

1.No matter FOB or CIF the price term is we would try our best to find a lowest freight cost for customers' reference.

2.The third-party inspection always gets real and true data from us and we will send production photos to customers if there is no inspection from the third-party.

3.Do our best to help customer arrange the shipment and customs clearance.

4.Installation, maintenance and repair instructions with full information.



Packing terms

  1. Panel and post all bulk in the container
  2. Panel with pallet (steel or wooden material) post packing using bubble film bulk in the container
  3. Panel and post all packing with pallet in the container
  4. All the clips and caps packing in the carton box

RAL6005 녹색 V 메쉬 펜싱 PVC 코팅 3M 야외 보안 울타리 0
